Products Details

Meatures:
1.High Brightness,800*600 resolution (1024*768 optional)
2.VGA input
3.Adjustable stand, also can be installed on the desk
Specification:
Panel size | 12.1 inch TFT-LCD |
Visual size | 1245*185mm |
Standard Resolution | 800*600 (1028*764 is optional) |
Scale | 4*3 |
Number of Colors | 16.2M |
Brightness | LCD panel:300cd/m2 |
Response time | 8ms |
View angle | Horizontal:160° |
Vertical:130° |
Contrase ratio | 400/1 |
Video input format | (analog) RGB |
Connector | VGA (D-sub) |
Frequency | 30~80KHz/60~75Hz |
Power supply | External Power Supply:100 to 240V AC |
(DC 12V) |
Operation Environment | Workable Temperature:-10 to 60°C |
Storage temperature:-20 to 70°C |
Operate relative humidity:20% to 80%; |
storage relative humidity:10% to 90% |
Net weight | 2.5 Kgs/pcs |
Gross weight | 3.0 Kgs/pcs |
Power consumption | Max 18W |
Setup (optional) | 1) provide wall brackets for wall-mounting, |
VESA 75mm |
2) provide base to support the monitor |
OSD control | AUTO,+,POWER,-,MENU |
brightness,contrast ratio,auto adjustment,phase position,clock, Languages,function,Install,reset |
each minit box size | 333*135*295MM |
package size | 10PCS in a carton |
color | white/black |
Features | simple, speedy,flexible ,artistic appearance and low radiation |
Warranty | 1 year |





Company Information
SHENZHEN OSCAN TECHNOLOGYCO.,LTD is a high techcompany with R & D, production, management, sales and service together. We’re mainly engaged in POS Terminal, Touch screen Monitor, POS peripherals, CCTV/VGA/HDMonitor and the retated products.According to the requirements from customers, we have sucessfully designed a variety of unique solutions to the supermarket, restaurant, retail and other related places. We expot to American, Germany, Japan, Australia, UK , Turkey etc.
We are holding " Integrity,Innovation,Win together" as company's culture,with our own professional materials and production factories,our R&D,production,management,sales and service teams will try to supply the best quality and competitive price products to our esteemed customers.
We provide ourselves on not just earning your business, but earning your trust.If you're looking for a processor with competitive rates, no long term commitments,no application or setup fee, OSCAN is your choice.
Packaging & Shipping


We delivery by lowest cost transportation, custom way is Air Express. If your quantity is enough we can use sea shipping . We always put you in the first place in our mind.
