- Products Status:Stock
- Screen Size:17"
- Type:Resistive
- Interface Type:D-SUB
- Interface Type:DVI
- Interface Type:Serial
- Interface Type:USB
- Resolution:1280 x 1024
- Place of Origin:CN;GUA
- Interface Type:HD+AV+TV
- Brand Name:OEM/ODM
- keywords:17 inch touch screen monitor capacitive for raspberry pi
- ratio display:4:3
- color:black
- brigtness:300cd/m2
- touch type:4 wire or 5 wire resistive touch
- input port:VGA
- Optional:HD/AV/TV
- Panel type:AU
- Viewing Angle:Viewing Angle
- Contrast Ratio Typically:800:1
17 inch touch screen monitor capacitive for raspberry pi
Main Features
1. fully new AU panel
2. Standard with Capacitive touch
3. Standard with VGA input ( hd/AV/TV is optional)
4. USB touch interface (RS232 touch is optional)
5. Different applications
6. Standard with 100*100mm VESA mounts,can be installed on the metal stand or
wall
Key Specification
System Parameters | LCD panel: | AU |
Working Voltage: | DC 11V-15V | |
Working Temperature: | -10~60° | |
Screen size: | 17 inches (4:3 diagonal) | |
Resolutions: | 1280(H)×1024(V) pixel | |
Dot pitch: | 0.285(H) ×0.285(V)mm | |
TV Receive System: | PAL/ NTSC/SECAM wide application range | |
Brightness: | 250cd/m2 | |
Contrast: | 800:1 | |
Power consumption: | ≤ 30W | |
Scanning Frequency: | 60-75Hz | |
Color: | 16.7M | |
Product functions | Full Function Touch Panel for PC | |
VESA metal Stand Optional | ||
VGA Port( hd+AV+TV Optional) | ||
The Highest Resolution is to 1280×1024 | ||
Operated System is WIN9X,2000,ME,CE/UNIX Support WIN9X,2K,XP,CE,UNIX | ||
Touch function | Touch Type: | Capacitive touch |
Touch Interface: | USB or Serial COM(RS232) | |
Touch Response Time: | 8ms | |
Touch Sensitivity: | Fixed | |
Touch Pen Hitting Life: | >= 1milions times | |
Accessories | 1pcs LCD Monitor | |
1pcs Stand Shelf | ||
1pcs VGA Cable | ||
1pcs Instruction Manual | ||
1pcs AC/DC Power | ||
Some Screw for Fixing the Shelf
| ||
1. Q:Why should I choose OSCAN?
A:10 Years Professional Experience
LCD Touch Monitor manufacturer with professional production and QC teams, we have skilled workers and advanced facility and offer the latest cuttingedge technology POS Terminal, Touch screen Monitor, POS peripherals, CCTV/VGA/hd Monitor and the retated products. We have CE,FCC,ISO9001 ,EMC and RoHS ect certification. We pride ourselves on not just earning your business, but earning your trust.
2.Q: How is the warranty and after-sales service?
A:We have one year guarantee, during the time, once you have any quality problem, we will repair for free . As to the after-sell service, you can contact us anytime
Q: May I get a sample?
A:Of course. We can provide the sample to you when you send the products details.
And the leading time is 2-3 working days.
We delivery by lowest cost transportation, custom way is Air Express. If your quantity is enough we can use sea shipping . We always put you in the first place in our mind.
