Product Description

Main feature:
1.AU/Innolux fully new panel
2. Standard with 4 wire resistive touch (5 wire is optional)
3. Standard with VGA input ( HD/AV/TV is optional)
4. USB touch interface (RS232 touch is optional)
5. Different applications
6. Standard with 100*100mm VESA mounts,can be installed on the metal stand or wall
Specification:
Key Specification |
System Parameters | LCD panel: | AU/Innolux |
Working Voltage: | DC 11V-15V |
Working Temperature: | -10~60° |
Screen size: | 17 inches (4:3 diagonal) |
Resolutions: | 1280(H)×1024(V) pixel |
Dot pitch: | 0.285(H) ×0.285(V)mm |
TV Receive System: | PAL/ NTSC/SECAM wide application range |
Brightness: | 250cd/m2 |
Contrast: | 800:1 |
Power consumption: | ≤ 30W |
Scanning Frequency: | 60-75Hz |
Color: | 16.7M |
Product functions | Full Function Touch Panel for PC |
VESA metal Stand Optional |
VGA Port( HD+AV+TV Optional) |
The Highest Resolution is to 1024×768 |
Operated System is WIN9X,2000,ME,CE/UNIX Support WIN9X,2K,XP,CE,UNIX |
Touch function | Touch Type: | 4-wire 5 wire resistive optional |
Touch Interface: | USB or Serial COM(RS232) |
Touch Response Time: | 8ms |
Touch Sensitivity: | Fixed |
Touch Pen Hitting Life: | >= 1milions times |
Accessories | 1pcs LCD Monitor |
1pcs Stand Shelf |
1pcs VGA Cable |
1pcs Instruction Manual |
1pcs AC/DC Power |
Some Screw for Fixing the Shelf |




Interface:
*VGA+USB Touch
*VGA+HD+AV+TV+USB Touch



Metal stand Optional

Monitor Accessories
